Description
Main Features
- The working table of the vertical slotting machine tool is provided with three different directions of feed (longitudinal, horizontal and rotary).Therefore work object go through once clamping, Several surfaces in the machine tool machining,
- Hydraulic transmission mechanism with sliding pillow reciprocating motion and hydraulic feed device for the working table.
- The sliding pillow has the same speed in every stroke, and the movement speed of the ram and the working table can be adjusted continuously.
- The hydraulic control tables have to ram commutation oil for oil reversing mechanism, In addition to hydraulic and manual feed outer. Even there single motor drive vertical, horizontal and rotary fast-moving.
- Use hydraulic feed the slotting machine, Is when the work is overturning back instantaneous feed. Therefore be better than mechanical slotting machine used drum wheel feed.
Specification
| Specification | BK5018 |
| X-axis stroke | 320mm |
| Travel Y-axis | 320mm |
| Max.pin length | 180mm |
| Sleeper movement times | 20-120min |
| Main motor power(servo motor) | 3.7KW |
| Workbench size | 600×320mm |
| Fast moving speed (X/Y) | 5/5m/min |
| Gyration angle | 360° |
| The distance between the working table and the slippery pillow | 600mm |
| Max.load of worktable | 100KG |
| shape size | 1980×2046×1817mm |
| Machine tool weight(about) | 1800KG |
| Package dimensions | 2200/2100/2300mm |
Tersedia juga model lain.
