Description
TECHNICAL PARAMETERS
<span “=””>- Size: 1500 mm x 750 mm x 1800 mm; 120KG
<span “=””>- The power supply: three-phase AC380V, power < 500 VA.
<span “=””>- The power module:
Three-phase and four phase system, AC380V, 50Hz
Three-phase power switch with leakage protection
Equipped with emergency stop button and Main power、power supply indicator lamp
Provides power supply output of DC24V
– Gas source: by silent air pump
<span “=””>- Tool accessories<span “=””>
<span “=””>- Annex: Experimental jump line, commonly used tools, software disc
<span “=””>- Manual
TRAINING ITEMS
– PLC hardware and software
PLC hardware knowledge
Wiring training PLC
PLC internal resources for learning
Using of PLC programming software
Download、upload and online monitoring of PLC applications
– Pneumatic basic loop training
Single-acting cylinder reversing loop
Double-acting cylinder reversing loop
Single-acting cylinder speed control loop
Double-acting cylinder on-way speed regulation loop
Double-acting cylinder both way speed regulation loop
Speed changing-over loop
Buffering loop
Twice pressure control loop
Counting loop
Delay loop
Overload protection loop
Interlocking loop
Single cylinder single reciprocating control loop
Single cylinder continuous reciprocating action loop
Double-cylinder sequential action loop
Double-cylinder synchronization action loop
Unloading loop
Joint gate type shuttle valve application loop
Rapid escape valve application loop
– Experimental platform adopts two kinds of control mode: group of relay control and PLC control. It is equipped with common pneumatic components, suitable for teaching practice of machinery、mechanical and electrical integration.
– Operation area is aluminum panel, square pipe frame is provided with casters. On the right side is the control module of the platform, including the leakage protection function. PLC control module, host computer communication port, a relay control module, switch module. Below the desktop with cabinet, used for the storage of components
