SLOTTING MACHINE BK5030

Multi Sarana Industrindo menjual berbagai macam kebutuhan industri, seperti : metal conductivity tester, oil flow meter/oil control valve, paper thickness gauge, pressure gauge, alat ukur minyak, alat ukur makanan, alat ukur kimia, alat ukur metalurgi, alat ukur tenaga listrik, radiation detector, detektor radiasi, dosimeter alarm radiasi pribadi, alat detektor radiasi nuklir, Mesin Industri

Category: Tags: ,

Description

Main Features

  • Synchronous belt drive,low noise,high transmission power
  • main motor:servo motor
  • Y ball screw :double nut preload
  • Perpendicularity of Z/Y≦0.02mm
  • Optional configuration over numerical control rotary table(with chuck)
  • All-closed protection



Specification

Specification BK5030
The maximum length of ram 300mm
Ram adjustment stroke 300mm
Number of ram movement 20/80n/min
Working desk size 550×405mm
table travel(X,Y) 280×330mm
The distance between the axis of the tool bearing hole and the forearm of the column 505mm
The distance between the end face of the cutter head support hole and the table 540mm
X direction motor torque 6(N/M)
Y direction motor torque 6(N/M)
Fast-moving 5X(m/min)
5Y(m/min)
Ball screw(X) FFZD3205-3/P4
Ball screw(Y) FFZD3205-3/P4
Main motor power 3.7KW
Machine tool weight(about) 2800KW
package dimensions 2300/2200/2300mm





Tersedia juga model lain.
Untuk Info Harga Silahkan Hubungi 0858-7630-0414 (Fast respon)
