Description:

The stainless steel magnetic level gauge vac UHZ-618C17 operates based on the principles of magnetic coupling and buoyancy. It can be used for liquid level measurement and control in production processes in industries such as petroleum and chemical. When the liquid level in the tested container rises or falls, the float in the main tube of the liquid level gauge also rises or falls. The magnetic steel inside the float is transmitted to the on-site indicator through magnetic coupling, driving the red and white column to rotate 180°. When the liquid level rises, the column changes from white to red. When the liquid level drops, the column changes from red to white, indicating the actual height of the liquid level. Scope of application: Suitable for liquid level measurement of corrosive media. Adopting a new technology of stainless steel lined PTFE stretching and flanging, the liquid level gauge has no blind spots in measurement, reliable structure, and long service life. In addition to on-site instructions, it can also be equipped with remote transmitters and alarm control switches. The indication is novel, the reading is intuitive and eye-catching, and the direction of the observation indicator can be changed according to the user’s needs. The measurement range is large, and the indicating mechanism is completely isolated from the measured medium, resulting in good sealing and high reliability. Simple structure and low maintenance costs.



Parameters:

1. Accuracy: ± 10mm

2. Medium density: 0.5-2.0g/cm3

3. Working pressure: 2.5MPa

4. Working temperature: -20-100

5. Environmental vibration: frequency ≤ 25Hz, amplitude ≤ 0.5mm
