RZQW-03A Turbine Digital Speed Indicator Impact Sub Monitoring Device

Multi Sarana Industrindo menjual berbagai macam kebutuhan industri, seperti : metal conductivity tester, oil flow meter/oil control valve, paper thickness gauge, pressure gauge, alat ukur minyak, alat ukur makanan, alat ukur kimia, alat ukur metalurgi, alat ukur tenaga listrik, radiation detector, detektor radiasi, dosimeter alarm radiasi pribadi, alat detektor radiasi nuklir

Category: Tag:

Description

Description:

RZQW-03A Turbine speed striker monitoring device usually displays the turbine speed, and the internal memory function can store the emergency breaker striker “strike out”, “retract” and the “highest” speed of the unit in the instrument, when the corresponding key is pressed It can easily display the action speed and the “maximum speed” of the two impactors when they are “strike out” and “retracted”. The instrument also has an analog signal output corresponding to the rotational speed.
Parameter
  1. Input signal: 3pcs CS-1 speed sensors or 1pc CS-1 speed sensor + 2pcs CS-3 speed sensors.
  2. Display mode: 4-digit LED digital display.
  3. Number of tachometer teeth: 60 teeth.
  4. Measuring range: 0～9999 rpm.
  5. The speed of detection of the impactor of the emergency circuit breaker: n>2000 rpm.
  6. Speed detection accuracy: n＜±1 rev/min.
  7. Output current: DC4 ~ 20mA or 0 ~ 10mA (full scale output current corresponds to a speed of 3500 rpm), load resistance ≤ 500Ω.
  8. Output accuracy: Class 0.5.
  9. Speed alarm: “Super 1” is 3300 rpm, “Super 2” is 3420 rpm, both are normally open contacts.





Tersedia juga model lain.
Silahkan chat/WA ke no 0858-7630-0414 (Fast respon)
