JM-D-5KF Positive And Negative Intelligent Rotational Speed Monitor

Multi Sarana Industrindo menjual berbagai macam kebutuhan industri, seperti : metal conductivity tester, oil flow meter/oil control valve, paper thickness gauge, pressure gauge, alat ukur minyak, alat ukur makanan, alat ukur kimia, alat ukur metalurgi, alat ukur tenaga listrik, radiation detector, detektor radiasi, dosimeter alarm radiasi pribadi, alat detektor radiasi nuklir

Category: Tag:

Description

Description:

The Positive and negative intelligent rotational speed monitor JM-D-5KF is an upgraded product of JM-C-3ZF.JM-D-5KF Intelligent Reversal Speed Monitor is the latest product specially designed and manufactured by Yoyik for rotating machinery speed and direction measurement, overspeed and reverse protection, zero speed and turning speed. The monitor is an intelligent instrument based on high- performance embedded chip. The parameters can be set directly through the instrument panel keyboard. It can receive the input signals of eddy current sensor system, magnetoelectric speed sensor, Hall speed sensor, and photoelectric sensor, continuously measure and monitor the machine speed and rotation direction, and provide overspeed and reverse protection monitoring for rotating machinery.

STANDARD FUNCTION of Positive and negative intelligent rotational speed monitor JM-D-5KF

  • Query the basic setting parameters of the instrument;
  • Provide DC power supply with overvoltage protection and short circuit protection for sensors
  • Overspeed, zero speed overrun discrimination, status indication and output of monitoring values;
  • Speed measurement range, number of teeth, alarm value, etc. are programmable;
  • Programmable definition of rotation direction;
  • The first and second relays of the instrument are used for overspeed warning and hazard control, and interlocking can be switched on or off; The third relay is used for reverse alarm control; The fourth relay is used for low speed alarm control;



Tersedia juga model lain.
Silahkan chat/WA ke no 0858-7630-0414 (Fast respon)
