Description:



Jacking device is an important part of the steam turbine unit. It jacks the rotor when the turbine turns to heat up or cool down in unit starting-up or shutting-down. Jacking oil must be clean to ensure the safety operation of the jacking devices and the whole unit.

Jacking oil filters are installed on the jacking oil pump. When high pressure alarm of oil filter is detected, or leakage occurs in the working filter, should change to the back-up filter. The impurities in the oil flowing out of the pump reach a certain cleanliness by filtering. After the pump is filtered, it can effectively prevent the damage of the top shaft oil pump, ensure the smooth operation of the top shaft oil pump and prolong the service life of the oil pump.

Regularly replacing the filter element of the turbine jacking oil pump is very important because as the usage time increases, more and more impurities will gradually accumulate in the filter element, resulting in a decrease in filtration efficiency and even causing problems such as insufficient lubricating oil flow or unstable pressure. Therefore, for the operation and maintenance of the steam turbine, it is essential to regularly replace the filter element of the jacking oil pump of the steam turbine.



Regular Model:



1. Double Drum Filter Element 3PD110x250A25C-1

2. Jacking Oil Pump Inlet Filter Element SFX-660*30

3. Jacking Oil Pump Inlet Filter Element DQ6803GA20H1.5C

4. Jacking Oil Pump Outlet Filter Element HBX-250*10

5. Jacking Oil Pump Inlet Filter Element SFX-850*20

6. Jacking Oil Pump Outlet Filter Element DQ8302GA10H1.5C

7. Automatic Back Flushing Filter ZCL-1-450B

8. Plate Filter 9PP80 250A10C-1

9. Lubricating Oil System Filter Element QF9732W50HPTC-DQ





Tersedia juga model lain.
