Description

TECHNICAL PARAMETERS

Power: AC 380V±10%, 50HZ, ≤1500W

Size:1700mm×700mm×1600mm （L*W*H）<span “=””>

Working temperature: 0~+50℃

Storage temperature: -20℃~+80℃

Humidity: 40~90%RH

This equipment is consisted by training bench, power module, assessment module, thyristor module, IGBT and MOS tube module, trigger and driving module. Bench completes experiments of power electronic fault setting, thyristor training, IGBT training, MOS tube training and some other related experiments, training project.

XK-DLDZ2A is suitable for curricular training & teaching of power electronics, electrical and electronic, electric engineering. Trainer also can complete the training of primary, intermediate and advanced electrician.

Advanced system: system PWM signal adopts 32-bit cortex-M3 core chip, high-speed calculation, high precision, 6-way complementary signal output, adjustable signal frequency.

High security: The connectors of training bench are the insulation socket with jacket. The system includes electric leakage protection, short circuit protection, over current protection, etc.

Various combination methods: It adopts frame structure, including 4 experiment modules which could be moved freely.
