Vertical Drilling Machine Z5040T

Multi Sarana Industrindo menjual berbagai macam kebutuhan industri, seperti : metal conductivity tester, oil flow meter/oil control valve, paper thickness gauge, pressure gauge, alat ukur minyak, alat ukur makanan, alat ukur kimia, alat ukur metalurgi, alat ukur tenaga listrik, radiation detector, detektor radiasi, dosimeter alarm radiasi pribadi, alat detektor radiasi nuklir, Mesin Industri

Category: Tags: ,

Description

Main Features

  • Drilling,tapping
  • 2 speed strong power motor
  • Automatic tools ejectors
  • 2 steps power feed 0.1-0.2mm/rev



Specification

Specification Z5040T
Max. drilling capacity 40mm
Threading in steel & last iron M20&M24
Spindle travel 180mm
Spindle taper M.T.#4
Spindle power feed 2steps/0.1-0.2mm/rev
Spindle speed 50-1450rpm
Width of T-slot 18mm
Max.distance from spindle axis to surface of column 350mm
Max.distance from spindle end to surface of table 770mm
Max.distance from spindle end to surface of base 1210
Diameter of column 150mm
Table size 560×560
Base size 730×500
Motor power 0.85/1.5kw
N.W/G.W 465kg/615kg
Packing size(L×W×H) 2270×690×1100mm







Tersedia juga model lain.
Untuk Info Harga Silahkan Hubungi 0858-7630-0414 (Fast respon)
