Induction Heating Machine – AT Series Specifications

This induction heater is designed for melting applications with a capacity of up to 1 kg and a heating time of 5–10 minutes. It is also suitable for annealing and brazing processes. For higher power requirements, please contact the administrator via WhatsApp: 0858-7630-0414.

Models Available

  • AT-15: 15 kW
  • AT-25: 25 kW

General Specifications

1. Power Input:

  • AT-15: Single Phase 220V, 50/60 Hz
  • AT-25: 3 Phase 380V, 50/60 Hz

2. Oscillating Power (Max):

  • AT-15: 15 kW
  • AT-25: 25 kW

3. Maximum Input Current:

  • AT-15: 37 A
  • AT-25: 24 A

4. Oscillation Frequency:
30 – 100 kHz

5. Cooling System Requirements:
Water pressure >0.2 MPa, flow rate 2–6 L/min, temperature ≤ 40°C

6. Duty Cycle:
100% continuous operation

7. Dimensions:

  • AT-15: 500 × 210 × 460 mm
  • AT-25: 550 × 240 × 480 mm

8. Net Weight:

  • AT-15: 21 kg
  • AT-25: 28 kg

9. Cable Length:
2 – 6 meters



Applications:
Melting, annealing, brazing, and various industrial heating processes requiring precise and efficient induction heating.

Additional information

Weight 32 kg
Model

AT-15, AT-25
