OMRON E2K-F10MC1 Proximity Sensor – Specifications

Product Type:
Capacitive Proximity Sensor (Flat Type)

Brand:
OMRON

Model:
E2K-F10MC1

Electrical Data

Operating Voltage: 12 – 24 VDC (operating range 10 – 30 VDC)
Current Consumption: max. 10 mA at 24 VDC
Output Type: NPN open collector
Switching Capacity: up to 100 mA at 30 VDC
Operation Mode: NO (Normally Open)

Sensing Performance

Sensing Distance: 10 mm ±10%
Setting Distance: 0 – 7.5 mm
Response Frequency: approx. 100 Hz
Detectable Objects: conductive and non-conductive materials
Standard Target: grounded metal 50 × 50 × 1 mm

Mechanical Data

Connection Type: Pre-wired cable, 2 meters
Housing Material: Heat-resistant ABS resin
Sensing Face: ABS resin
Protection Degree: IP66
Dimensions: approx. 50 × 20 × 10 mm

Environmental Conditions

Operating Temperature: -10°C to +55°C
Storage Temperature: -10°C to +55°C
Humidity: 35% – 95% RH (non-condensing)

Features

Flat-type compact design
High stability capacitive detection
Suitable for detecting level, position, and presence of materials
Built-in reverse polarity and surge protection
Easy installation in industrial environments

Application

Used as a proximity sensor in industrial automation systems for detecting objects, material presence, and position control in machinery and production lines.
