Description
Functions and Features:
• Stainless steel housing.
• Keypad controls running speed, reverse direction, start/stop, full speed, easy operation.
• Applicable pump heads: YZ35, 2xYZ35.
• Single-channel flow range: 0.4-13 (L/min).
• Speed resolution: 1 rpm.
• Four-digit digital LED indicator displays operating speed.
• Brushless motor drive, maintenance-free.
• Stainless steel housing, easy to clean, highly resistant to corrosion from acids, alkalis, sodium, and organic solvents.
• Conformal coated circuit board for dust and moisture resistance.
• External high-low electrical level controls start/stop, reversible direction and easy routing function, optically coupled isolator, selectable 5V, 12V, and 24V. External analog control adjusts the rotation speed, selectable from 0-5V/10V, 4-20mA.
• RS485 interface, MODBUS protocol available, easy to connect to other equipment.
Parameters:
• Single-channel flow range: 0.4-13L/min
• Flow accuracy: ＜3%
• Speed range: 30-600rpm.
• Speed resolution: 1 rpm
• Power supply: AC 220V±10%, 50Hz, 110V/60Hz
• Power consumption: ＜300W
• External control: Input electrical levels: 5V, 12V (standard), 24V (optional).
• External communication interface: RS485 communication interface, supports MODBUS protocol.
• Ambient temperature: 0~40℃
• Relative humidity: ＜80%
• IP Class: IP31
• Dimensions (LxWxH): 340mmx235mmx175mm
• Weight: 13KG
Specifications:
1. Channel:
• WG600S-D1: 1
• WG600S-D2: 2
2. Pump Head:
• WG600S-D1: YZ35PPS
• WG600S-D2: YZ35PPS x 2
3. Tube Size:
• WG600S-D1: 73#, 82#
• WG600S-D2: 73#, 82#
4. Single Channel Flow Rate (ml/min):
• WG600S-D1: 400-13000
• WG600S-D2: 400-13000
Other models are also available.
