Emergency Trip System (ETS)

Multi Sarana Industrindo menjual berbagai macam kebutuhan industri, seperti : metal conductivity tester, oil flow meter/oil control valve, paper thickness gauge, pressure gauge, alat ukur minyak, alat ukur makanan, alat ukur kimia, alat ukur metalurgi, alat ukur tenaga listrik, radiation detector, detektor radiasi, dosimeter alarm radiasi pribadi, alat detektor radiasi nuklir, Emergency Trip System

This product is currently out of stock and unavailable.

SKU: N/A Category: Tag:

Description

Description:

Steam turbine emergency trip system (ETS) receives the stop signal from a local first meter or TSI secondary meter according to the safe operation requirements of steam turbines, control the shutdown solenoid valve to let the steam turbine shutdown in emergency, for protecting the safety of steam turbine. Emergency trip system (ETS) monitors the parameters as below. If any parameter exceeds the normal range, the shutdown valve will stop all the Actuators.

ETS monitors the steam turbine’ s operation based on the sensors. Monitored parameters are as below��

Turbine over-speed 110%

EH oil low pressure

Lubricating oil low pressure

Condenser low vacuum degree

Thrust bearing abrasion (large axial displacement)

Trip signal remotely controlled by users

ETS system consists of an emergency trip block for installing shutdown solenoid valve and status pressure switch, four test trip blocks for installing pressure switch and test solenoid valve, speed sensors, a control cabinet for installing electric and electronic hardware, and a remote control test operation panel.



Regular Spares:

  • Actuator Trip Valve
  • Emergency Trip Throttle
  • Emergency Trip Valve
  • Trip Module Check Valve
  • Trip Pressure Switch
  • Trip Slide Valve Assembly
  • Trip Solenoid Valve
  • Trip Valve/Shutoff Valve





Tersedia juga model lain.
Silahkan chat/WA ke no 0858-7630-0414 (Fast respon)

Additional information

Model

Actuator Trip Valve, Emergency Trip Throttle, Emergency Trip Valve, Trip Module Check Valve, Trip Pressure Switch, Trip Slide Valve Assembly, Trip Solenoid Valve, Trip Valve/Shutoff Valve
