BWR-04JJ Oil Level Transformer Winding Thermometer

Multi Sarana Industrindo menjual berbagai macam kebutuhan industri, seperti : metal conductivity tester, oil flow meter/oil control valve, paper thickness gauge, pressure gauge, alat ukur minyak, alat ukur makanan, alat ukur kimia, alat ukur metalurgi, alat ukur tenaga listrik, radiation detector, detektor radiasi, dosimeter alarm radiasi pribadi, alat detektor radiasi nuklir

Category: Tag:

Description

Parameters:

  1. Temperature transmitter power supply: AC/DC (100-260) V, frequency 50Hz;
  2. Output signal: passive or active DC (4-20) mA current signal;
  3. Working conditions: ambient temperature (-40+55), relative humidity $95% RH,
  4. Measuring range: (0150)0:
  5. Accuracy: Level 2.0 (according to standard JB/T8450-2005);
  6. Switch performance: four sets of adjustable switches, the switches can be set arbitrarily within the full range (up to 6 sets of switches according to user requirements);
  7. Switch action point: K1=50°C, K2=75°C, K3=100°C, K4=120°C;
  8. Switch action error: +2°C, switch switching error: (6+2)°C; Switch rated power: AC220V/5A, DC220V/3A;
  9. Temperature bulb size: 014, insertion depth not less than 150 mm;
  10. Mounting thread: (M27x2)mm or (M33x2)mm;
  11. Capillary length: 6m, 18m can be made according to user requirements;
  12. Protection level: IP55.



Tersedia juga model lain.
Silahkan chat/WA ke no 0858-7630-0414 (Fast respon)
