Bench Lathe C0636B

Multi Sarana Industrindo menjual berbagai macam kebutuhan industri, seperti : metal conductivity tester, oil flow meter/oil control valve, paper thickness gauge, pressure gauge, alat ukur minyak, alat ukur makanan, alat ukur kimia, alat ukur metalurgi, alat ukur tenaga listrik, radiation detector, detektor radiasi, dosimeter alarm radiasi pribadi, alat detektor radiasi nuklir, Mesin Industri

Description

Main Features

Precision ground and hardened bed ways.
The spindle is supported with precision roller bearings.
Headstock gears are made of high quality steel, ground and hardened.
Easy operating speed change levers.
Removable gap is provided for larger diameter work.
Easy operating gear box has various feeds and thread cutting function.

Specification

Specification	C0636A (C0636B)
Distance between centers	1000mm
Max. swing over bed	360mm
Max. swing over cross	212mm
Max. swing in gap	491mm
Width of bed	187mm
Spindle speed range	8 steps 70-2000rpm (51mm as 8 steps 90-2000rpm)
Spindle bore	38mm (51mm as aptional)
Spindle nose	D4 (51mm: D5)
Spindle taper	MT5 (51mm: MT6)
Center height	178mm
Threads metric pitches	0.4-7mm/26kinds
Threads imperial pitches	4-56TPI/34kinds
Compound rest travel	90mm
Cross slide travel	170mm
Longitudinal feeds	0.052-1.392mm/rev /32kinds
Cross feeds range	0.009-0.253mm/rev (Metric lathe) 0.015-0.402mm/rev (Inch lathe)
External diameter	32mm
Max. travel	100mm
Taper of bore	MT3
Spindle motor power	1.5kw
Coolant pump power	40w
Tool section	16*16mm
Packing dimension	19357501500mm
Net/Gross weight	600/700kg
