Description

Stud Rectifier Diode 300UR120 – Specifications

Product Type: Stud Mount Rectifier Diode

Electrical Specifications:
Average Forward Current: 300 A
Repetitive Peak Reverse Voltage: 1200 V
Forward Voltage Drop: approx. 1.2 – 1.4 V
Surge Current Capability: High surge current tolerance

Mechanical Data:
Package Type: Stud / screw mount
Mounting: Heatsink / bolt-on installation
Housing: Metal body with insulated base
Cooling: Requires external heatsink

Performance Features:
High current and voltage capability
Efficient heat dissipation
Reliable rectification performance
Robust construction for industrial use

Applications:
Industrial rectifier systems
Welding equipment
Battery chargers and DC power supplies
Induction heating systems
Motor drives and power control systems
