Universal Milling Machine ZX6350ZA

Multi Sarana Industrindo menjual berbagai macam kebutuhan industri, seperti : metal conductivity tester, oil flow meter/oil control valve, paper thickness gauge, pressure gauge, alat ukur minyak, alat ukur makanan, alat ukur kimia, alat ukur metalurgi, alat ukur tenaga listrik, radiation detector, detektor radiasi, dosimeter alarm radiasi pribadi, alat detektor radiasi nuklir, Mesin Industri

Category: Tags: ,

Description

Main Features

  • Universal milling head, machining flexibility
  • X axis mechanical feed
  • Vertical and horizontal multifunctional drilling milling machine
  • Gear transmisson milling head, automatic feed



Specification

Model Unit ZX6350ZA
Spindle taper MT4/ISO40
Distance vertical spindle to table mm 100-500
Distance horizontal spindle to table mm 0~400
Distance spindle to column mm 240~710
Spindle seeds range r/min (8 steps)90-2000(vertical)
(12 steps)40-1300(horizontal)
Automatic Feed Series sleeve mm 120(vertical)
Table size mm 1370×320
Table travel mm 800/320/400
Distance horizontal spindle to arm mm 175
Table feeds range(x/y) mm/min 40-605(8 steps)(max.810)
T of table (no./width/distance) mm 3/14/70
Main motor kw 2.2
Motor of table power feed w 1000
Coolant pump motor w 40
N.W/G.W. kg 1550/1700
Overall dimension mm 1700×1480×2150





Tersedia juga model lain.
Untuk Info Harga Silahkan Hubungi 0858-7630-0414 (Fast respon)

Additional information

Weight 1700 kg
